Description | Aluminum base frame and superstructure Air suspension with axle compensation and wheel shock absorbers for 100 km/h Overrun brake with automatic reverse and reinforced brake drums Full-height rear flap as drive-on ramp with checker plate tracks and internal espagnolette lock, lockable Outer frame 90 mm high in reinforced design with integrated utility rail for holding lashing rings that can be adjusted lengthways Front barrier bar with perforated rail, adjustable 2 LED interior lights with switch, 1 at the rear top left and 1 at the front top right Automatic support wheel in reinforced design between the drawbars Lighting according to StVZO 12 Volt Plug 13 pin Tarpaulin and aluminum bows made of aluminum tube profiles, welded Roof struts slightly tapered upwards Sliding tarpaulin on the right and left side with tensioning frame at the front, lockable, bottom quick-release lock with square key Internal dimensions: 5500×2250 mm Clearance width 2170 mm Clearance height1800 mm Loading height 680 mm Tiltable V-drawbar 225/55 R12 C tires Load capacity 900 kg per wheel at 130 km/h, at 5.2 bar Floor 15mm screen-printed combination panels front-mounted tip with diagonal cut 45°, which is added to the loading area, beveled at the front, with diagonal cut of the corners, this offers a lower air resistance and unique driving comfort Additional inner length of 100 mm each, extended to 6000 mm Additional inner width 50 mm each, widened to 2350 mm Additional folding access ramps for loading very flat pushchairs Door at the top front right, can be opened forwards, with gas spring as door holder and internal espagnolette lock, lockable Lightly corrugated aluminum profile base, 30 mm thick with cross corrugation Milled holes in the aluminum base for wheel chocks along the entire length, incl. 4 wheel chocks and 4 lashing straps for optimum transport securing Storage recesses for tire sets and tools in the loading area in front of, behind and above the axle Cover shelf for the storage recesses, made of aluminum floor profiles, can be removed individually for each compartment Electric winch, pulling force 2.5 t with battery and 230 V charger, additional charging of the battery via PIN 9 of the 13-pin plug Additional feed socket at the front under the body to be able to charge the battery with 230V 16A during longer downtimes Winch can be moved transversely, mechanical Plastic winch cable mounted on the winch instead of steel cable 2-channel radio control for electric winch Alarm system with radio remote control with ultrasonic sensors, door contacts and motion detectors Rear view camera connected to separate monitor via radio Mirror system at the front of the body, mirrors right, left and center LED interior light in addition to the standard ones in all 4 corners Spare wheel 12” with holder Special additional ramps for loading very flat vehicles, can be attached to the fold-out ramps, incl. Transport bracket on the folding ramps permissible total weight 3,500 kg FOR US, THE CONDITION AND THE GUT FEELING ARE DECISIVE, THE PRICE IS IN SECOND PLACE. Here we have a model with many extras, which you can also see in the description. The drawbar and the flap are unlocked. The cargo bed is then tilted by pushing it down. The body tilts when driving on it. As soon as it has reached the optimum drawbar load, it tilts back into the driving position. They are then secured with eccentric locks. //*EXCHANGE, PAYMENT OR PAYMENT OF YOUR VEHICLE, AS WELL AS FINANCING POSSIBLE!All information without guarantee* You will find more offers on our homepage: www.derfaller.de The description and specified data do not constitute a warranty and are not binding. The purchase agreement concluded at the dealership when purchasing the vehicle is binding. Errors and prior sale excepted! |
